Altair Simulation Analysis

From the design and manufacture of small recreational crafts and large oil tankers to the most technologically advanced aircraft carriers, Altair has assisted the world’s leading shipbuilders and boat designers to develop higher performing, safer and lower cost vessels through the application of simulation technology. Altair helps naval architects address complex engineering challenges and mitigate environmental risks associated with seagoing loads including structural, hydro, dynamic, thermal and fatigue, as well as above surface and underwater weapon threats for the military and homeland security.


Simulation for Safer Sailing

Simulation assists the engineering of safer marine vessels and robust offshore structures with modeling of collision, sloshing, slamming, underwater explosive, structural strength assessment, vibration, noise performance, heat and cooling analyses, as well as antenna design. It is important to ensure designs meet industry classification and society regulations, capture knowledge and increase development efficiency through customization and automation technologies and expertise.

Reduce Total Ownership Cost

Increased global competition requires a faster and more efficient ship design and certification process to shorten the turnaround time and reduce cost. To stay competitive in the global marketplace, shipbuilders are looking for ways to reduce production and lifecycle maintenance costs. Increase design efficiency and minimize material usage to reduce manufacturing and operational cost, all while increasing fuel efficiency with Altair’s leading structural andcomputation fluid dynamics (CFD) optimization technologies.

Modeling and Assembly


Meshing matters: HyperMesh’s high quality mesh leads to

accurate result. HyperWorks let engineers be engineers,

operating in a neutral, integrated and easy-to-use environment

that enables collaboration and process automation

Meshing matters: HyperMesh’s high quality mesh leads to accurate result. HyperWorks let engineers be engineers, operating in a neutral, integrated and easy-to-use environment that enables collaboration and process automation

Advanced and Comprehensive Simulation Solutions


Integrated solvers platform with best-in-class scalability, quality, robustness. Solutions include structural (OptiStructand RADIOSS), CFD (AcuSolve), multi-body dynamics (MotionSolve), and electromagnetic (FEKO) analysis. Altair’s solvers are optimization-ready and can be coupled for Smart Multiphysics analysis.

Productivity Benefits – Pre-Processing


• Most preliminary FE analyses are carried out using a coarse mesh global ship model built from 2D AutoCAD drawings. Refined sub-models are required to further assess local details. These sub-models can be time consuming to generate using traditional tools.

• The re-meshing and refinement tools in Hypemesh allow coarse models to be quickly refined to the desired mesh density allowing the user to take full advantage of prebuilt coarse FE models and save modeling time

Productivity Benefits – Pre-Processing
Productivity Benefits – Post-Processing

Productivity Benefits – Post-Processing


• Ship FE models are often difficult to navigate to establish what areas are failing to meet the acceptance criteria.

• The advanced query tools in HyperView automatically pinpoint which elements or components fail to meet the acceptance criteria. This saves having to manually check the whole model
